EC-1-DV Series Mini-Split Condensate Pumps
EC-1-DV Series Mini-Split Condensate Pumps
Condensate needs to be drained from your HVAC equipment to maintain proper function. The EC-1-DV Series of mini-split condensate pump is an automatic condensate removal system designed to remove the water from a ductless mini-split air conditioner evaporative coil when gravity-feed drainage is not possible or practical. Series models include improved noise reduction, reliable solid-state switching technology, and easy to install mounting brackets to create a pump that benefits contractors, installers, and end-users.
Features & Benefits
- Dual Voltage 110 - 240 V 50/60 Hz
- 2.5 gph @ 1 ft (9.5 lph) flow
- 33 ft (10 m) shut-off (max. recommended)
- Hall effect switching
- Large inlet filter
- Multi-size hose drain adapter fits all popular drain hose connectors
Overview
The Little Giant EC-1-DV mini-split condensate pump is used to remove condensate from wall mount and ductless mini-split cooling systems up to 34,000 BTU. It is designed to accommodate multiple electrical requirements within one pump. The DV suffix indicates that the pump is capable of operating from a wide range of supply voltage to maintain consistent pump performance.
Specifications
| Capacity | 2.5 gph @ 1' |
| Shut Off | 33' (10 m) |
| Max. Liquid Temp. | 140 °F (60 °C) |
| Discharge | 1/4" (6 mm) I.D. Pump Discharge Outlet |
| Electrical | 100-240 V, 50/60 Hz, 0.18 A |
| Operation | Automatic |
Performance
| Head | GPH (LPH) |
| 1' | 2.5 (9.5) |
| 5' | 1.8 (6.8) |
| 10' | 1.5 (5.7) |
| 20' | 1.2 (4.5) |
